Communication Lab

NI USRP-292x transceivers provide relevant, hands-on laboratory
learning in RF and communications as an affordable teaching
solution. The NI USRP hardware and LabVIEW software
combination offers students a unique and relevant opportunity to
experiment with a wide range of real-world signals in introductory
communications and digital communications laboratories. With this
solution, students can focus on the practical implementation of
theoretical algorithms and real-world impairments earlier in the
curriculum.

Equipment

70MHz, 2 Channel, Digital Oscilloscope 25MHz,2 Ch, Function generator 25MHz,2Ch,Arbitrary Function generator . USB Realtime spectrum analyzer Vector signal generator 4GHz

SignalVu-PC is the foundation of RF and vector signal analysis
software that helps you easily validate RF designs. It is based on the
signal analysis engine of the RSA5000 Series real-time signal
analyzers and runs on your computer or Windows tablet. You can
now move your analysis of acquisitions off the instrument and
anywhere. SignalVu-PC is also the companion software that runs the
analysis for the Tektronix USB real-time spectrum analyzers.
Whether your design validation needs include wideband radar, high
data rate satellite links, wireless LAN or frequency hopping
communications, the SignalVu-PC comprehensive suite of tools and
application software can speed your time-to-insight by showing you
the time-variant behavior of these signals.

Ansys HFSS is a 3D electromagnetic (EM) simulation software for designing and simulating high-frequency electronic
products such as antennas, antenna arrays, RF or microwave components, high-speed interconnects, filters, connectors, IC
packages and printed circuit boards.
